PRODUCT SPECIFICATIONS
Model Information
| Name | Value |
|---|---|
| Model | JT4HC |
| UPC | 671080720449 |
Unit Dimensions
| Name | Value |
|---|---|
| Overall Dimensions (IN) | 21.25 x 46.187 x 23.5 |
| (W) Width (IN) | 46.18 |
| (W2) Secondary Width (IN) | 29.375 |
| (D) Depth (IN) | 21.25 |
| (H) Height (IN) | 23.5 |
| (WL) Width between legs | 17.375 |
| (DL) Depth between legs | 25.5 |
| Product Opening Dimensions (IN) | 1.5 - 3 |
| Overall Dimensions (CM) | 53.8 x 117.3 x 59.7 |
| (W) Width (CM) | 117.3 |
| (W2) Secondary Width (CM) | 74.6 |
| (D) Depth (CM) | 53.8 |
| (H) Height (CM) | 59.7 |
| (WL) Width between legs (CM) | 44.1 |
| (DL) Depth between legs (CM) | 39.4 |
| Product Opening Dimensions (CM) | 3.8 - 7.6 |
Electrical
| Name | Value |
|---|---|
| Amps | 23.6 |
| Cord Length (IN) | 54 |
| Cord Length (CM) | 140 |
| Hz | 60 |
| Plug | NEMA 6-30P |
| Voltage | 208 |
| Watts | 4950 |
Construction
| Name | Value |
|---|---|
| Countertop or Drop-In | Countertop |
| Food Type | Standard Breads, Specialty Breads, Buns, Bagels |
| 901 | $68.20 | |
| BEARING ASSEMBLY 5/16 | B201100 | $23.90 |
| SO2 14.5" CRUMB TRAY ASSM | B205129 | $106.80 |
| WIRE CONVEYOR BELT 14.5" X 42" | B205138 | $181.20 |
| CT4 18" TOAST CHUTE | B300013 | $96.90 |
| CT4-DUAL SIDE PANEL | B300230 | $92.40 |
| CT4-2000 NOSE GUARD | B300807 | |
| SPRING .038" DIA 1.500" LENGTH | B400261 | $3.00 |
| LEGS BLACK 1" 1/4-20 | B400300 | $15.60 |
| STRGHT 12 GA STRAIN RLF BSHNG | B400321 | $0.70 |
| TERMINAL BLOCK 5 POSITION | B401033 | $15.40 |
| CORD POWER 12/3 60" 6-30P | B401051 | $57.30 |
| CORD FAN HP-75.24-A | B401060 | $11.90 |
| RESET SWITCH | B401100 | $40.80 |
| SWITCH 240 V | B401102 | $45.00 |
| SWITCH ROTARY POWER SAVER | B401103 | $56.30 |
| SWITCH FAN CERAMIC | B401107 | $40.80 |
| MOTOR DRIVE 208/240V RMS 344 | B401201 | $196.90 |
| MOTOR DRIVE 208/240V REVERSED | B401203 | $188.00 |
| MOTOR FAN | B401211 | $76.50 |
| GUARD FAN | B401220 | $8.50 |
| SPROCKET 25B17-8MM | B401300 | $26.80 |
| SHAFT DRIVE 14.5" | B401342 | $51.90 |
| SHAFT IDLER | B401349 | $60.10 |
| FRONT BEARING SPRING-LOADED | B401352 | $23.70 |
| CHAIN LADDER 13.25." | B401386 | $24.50 |
| CHAIN LADDER 26" | B401387 | $31.40 |
| UPPER CHAMBER LABEL | B401423 | $55.70 |
| LOWER CHAMBER LABEL | B401424 | $57.80 |
| SILVER PUSH-ON KNOB | B405018 | $8.00 |
| SILVER PUSH-ON KNOB W/SET SCRW | B405019 | $14.70 |
